Model RR-212E-20PK-R1 / RR-212E-20PK-R2
CPU Socket Intel Socket:
LGA 2011 / 1366 / 1156 / 1155 / 1150 / 775 *

AMD Socket:
FM2 / FM1 / AM3+ / AM3 / AM2+ / AM2
CPU Support Intel:
Core™ i7 Extreme / Core™ i7 / Core™ i5 / Core™ i3 / Core™2 Extreme / Core™2 Quad / Core™2 Duo / Pentium / Celeron
AMD:
FX-Series / A-Series / Phenom™ II X4 / Phenom™ II X3 / Phenom™ II X2 / Phenom™ X4 / Phenom™ X3 / Athlon™ II X4 / Athlon™ II X3 / Athlon™ II X2 / Athlon™ X2 / Athlon™ / Sempron™
Dimension 120 x 80 x 159 mm (4.7 x 3.1 x 6.3 in)
Heat Sink Dimensions 116 x 51 x 159 mm (4.6 x 2.0 x 6.3 in)
Heat Sink Material 4 Direct Contact Heat Pipes / Aluminum Fins
Heat Sink Weight 465g (1.03 lb)
Heat Pipes Dimensions ø6mm
Fan Dimension 120 x 120 x 25 mm (4.7 x 4.7 x 1 in)
Fan Speed 600 – 2,000 RPM (PWM) ± 10%
600 – 1,600 RPM (PWM) ± 10% (EU Version)
Fan Airflow 24.9 – 82.9 CFM ± 10%
24.9 – 66.3 CFM ± 10% (EU Version)
Fan Air Pressure 0.3 – 2.7mm H2O ± 10%
0.3 – 1.7mm H2O ± 10% (EU Version)
Fan Life Expectancy 40,000hrs
Fan Noise Level (dB-A) 9 - 36 dBA
9 - 31 dBA (EU Version)
Bearing Type Long Life Sleeve Bearing
Connector 4-Pin
Fan Rated Voltage 12 VDC
Fan Rated Current 0.22A
0.19A (EU Version)
Power Consumption 2.64W
2.28W (EU Version)
Fan Weight 104g (0.23 lb)
