Sockel:

AM5 Sockel
Prozessor: AMD Ryzen™ 9000 Series Processors
AMD Ryzen™ 8000 Series Processors
AMD Ryzen™ 7000 Series Processors
Chipsatz: AMD B850
Speicher: AMD Ryzen 9000 / 8000 / 7000 Series Processors:
Supports Dual Channel DDR5 - 8000+(OC) MT/s, Non-ECC, Un-buffered Memory
2 x DDR5 DIMM Memory Slot, Max. Supports up to 128 GB Memory
Support Intel® Extreme Memory Profile (XMP) memory modules and AMD EXTended Profiles for Overclocking (EXPO) memory modules
  • Please refer to www.biostar.com.tw for Memory support list.
Grafik: Integrated Graphics Processor with AMD Radeon™ Graphics support:
  • 1 x DisplayPort
  • 1 x HDMI port
Steckplätze: 1x PCIe 4.0 x16
1x PCIe 4.0 x4
Storage: Total support 2 x M.2 Socket and 2 x SATA (6Gb/s) ports
AMD Ryzen 9000 / 8000 / 7000 Series Processors
1 x M.2 (Key M2) Socket (M2M_CPU):
Support M.2 Type 2260/2280 SSD module
Support PCIe 4.0 x 4 (64Gb/s) - NVMe SSD
AMD B850 Chipset
1 x M.2 (Key M2) Socket (M2M_SB):
Support M.2 Type 2280 SSD module
Support PCIe 4.0 x 4 (64Gb/s) - NVMe SSD
2 x SATA III Connector (6Gb/s):
Supports AHCI & RAID 0, 1, 10
  • Specifications vary by CPU types
Sound: Realtek ALC897
7.1 Channels, High Definition Audio, Hi-Fi (Front)
LAN: Realtek RTL8125D
10/ 100/ 1000/ 2500 Mb/s auto negotiation, Half / Full duplex capability
USB: 1 x USB 3.2 (Gen2) Type-C port
(1 via internal header)
6 x USB 3.2 (Gen1) port
(4 on rear I/O and 2 via internal header)
6 x USB 2.0 port
(2 on rear I/O and 4 via internal header)
Interne I/O Anschlüsse: 2 x SATA III Connector (6Gb/s)
1 x M.2 (E Key) Socket : Supports 2230 type Wi-Fi & Bluetooth module
1 x USB 3.2 (Gen2) Type-C Port
(each header supports 1 USB 3.2 (Gen2) Type-C port)
1 x USB 3.2 (Gen1) Header
(each header supports 2 USB 3.2 (Gen1) ports)
2 x USB 2.0 Header
(each header supports 2 USB 2.0 ports)
1 x 8-Pin Power Connector
1 x 24-Pin Power Connector
1 x CPU Fan Connector
1 x CPU water cooling connector (CPU_OPT)
1 x System Fan Connector
1 x Front Panel Header
1 x Front Audio Header
1 x Speaker Header
1 x Clear CMOS Header
1 x COM Port Header
1 x TPM Header
2 x LED Header (5V)
1 x LED Header (12V)
Rückseite I/O Panel: 2 x WiFi Antenna Port
4 x USB 3.2 (Gen1) Port
2 x USB 2.0 Port
1 x 2.5 Gigabit LAN port
3 x Audio Jack
1 x SMART BIOS UPDATE Button
1 x SMART BIOS USB Port
1 x HDMI® Port (HDMI®2.1)
1 x DP Port (DP1.2)
Formfaktor: Micro-ATX
Abmessungen : 23.5cm x 24.4cm
unterstützte BS :   - Microsoft® Windows® 10/11 64-bit
