Software Specification
|
|
|
Standards
|
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, CSMA/CA with ACK
|
|
Wireless Signal Rates With Automatic Fallback
|
11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
|
|
Frequency Range
|
2.4-2.4835GHz
|
|
Wireless Transmit Power
|
20dBm (max. EIRP)
|
|
Modulation Type
|
OFDM/CCK/16-QAM/64-QAM
|
|
Receiver Sensitivity
|
270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
|
|
Security
|
64/128 bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
|
|
Support Operating System
|
Windows 2000/XP/Vista
|
|
Hardware Specification
|
|
|
Interface
|
USB 2.0 Hi-Speed
|
|
Antenna Type
|
Internal Omni-directional Antennas
|
|
Certifications
|
CE, FCC
|
|
Operating temperature
|
0°C~40°C
|
|
Storage temperature
|
-40°C~70°C
|
|
Relative humidity
|
10% ~ 90%, non condensation
|
|
Storage Humidity
|
5%~95% non-condensing
|
|
Dimensions
|
93.5 x 26 x 11mm
|
